Magnetic Encoder

Technical features:

◆The accuracy of angle detection reaches 0.5%

◆ It has traditional analog output and multiple output interfaces such as I2C, SPI, PWM, etc

◆ Has multiple advantages such as high reliability and high precision

Product Details：

The encoding position sensor IC of QST is based on high-precision magnetic field detection technology. The high-precision magnetic field detection technology used in QST's encoding position sensing IC provides a wide range of high-performance decoding chips for industrial, medical, robotics, automotive, and consumer applications, enabling angle detection accuracy to reach 0.5%; A sensor that measures the absolute and relative positions of the minimum possible rotation angle. And provide various digital 3x3mm2 packages, which can meet the size requirements of most occasions. At the same time, our patented technology enables the encoding position sensor to be protected from infinite lifespan and suitable for temperatures ranging from -40 to+150 degrees Celsius, as well as external stray magnetic fields. This provides a more stable and cost-effective solution to traditional analog output and multiple output interfaces such as I2C, SPI, PWM, etc.

Application of magnetic encoder chip in motors:
